CP Series

The RF electrical connector CP series is an imitation of the Russian series of products, used for the separation and connection of wireless electronic devices, cables and instruments or components of the same instrument.
Technical documentation Datasheet CP Series

CP Series (СР-50, СРГ-50, СР-75, СРГ-75)
The RF electrical connector CP series is an imitation of the Russian series of products, used for the separation and connection of wireless electronic devices, cables and instruments or components of the same instrument. It has the structure of cables, instrument connections, transfers, tees and four-way structures. . Plugs and sockets have threaded, plug-in, and bayonet connections. Impedance is 50Ω and 75Ω.

Technical characteristics: (CP-50/75)
• Ambient temperature: -60℃ ~ +85℃
• Sinusoidal vibration: frequency 5~2500 (Hz); acceleration 15g
• Mechanical impact: single acceleration 150g multiple times 75g
• Contact resistance: ≤0.010
• Insulation resistance: ≥ 1000 ΜΩ
• Working voltage: 10V
• Working current: 0.5V (Technical conditions: ГЕО.364.235ТУ)
