R255EC Series

R255EC Series circular fiber optic connector. The R255EC series circular fiber optic connector is a multi-core environment-resistant fiber optic connector developed on the basis of the R255EC series optical connector.

Technical documentation R255EC Series (ELIO)

Applications
The R255EC series circular fiber optic connector is a multi-core environment-resistant fiber optic connector developed on the basis of the R255EC series optical connector. The EC4531 contact has a bayonet locking structure, which can be easily installed in the connector without any removal tools. The rear end of the contact is equipped with a seal, and no tail cover or wire seal is required. It has excellent performance such as vibration resistance, pressure resistance, rain resistance, salt spray resistance, and dust resistance.
The EC4531 contact can be equipped with a No. 8 cavity adapter to meet the ARINC 600 series 8# contact installation hole requirements. The product is suitable for aviation, aerospace, electronics, weapons, ships and other fiber optic communication systems with requirements.

Technical details

Features
• Comply with GJB599A (MIL-DTL-38999) III series interface
• The socket is available in two options: square plate installation and nut fastening installation
• The outer shell can be selected from different materials and coatings to adapt to different environmental requirements
• The head seat uses a five-key circumferential identification positioning to achieve blind insertion and anti-misinsertion
• Adopts three-head threaded quick connection with anti loosening mechanism
• Adopts standard 2.5 ceramic pins and ceramic sleeves to achieve precise fiber docking
• The contact has a bayonet locking structure, which can be easily loaded and unloaded without any tools
• Equipped with a No. 8 cavity adapter to ensure optical performance.

Main Specifications
• Insertion loss:
Multimode ≤0.3dB (95% of samples meet the requirements), ≤0.7dB (100% of samples meet the requirements);
Singlemode ≤0.5dB (95% of samples meet the requirements), ≤0.9dB (100% of samples meet the requirements);
Operating temperature: -55 ℃~+85℃ (depending on the optical cable used)
• Vibration: 5Hz~3000Hz
• Mechanical life: 500 cycles
• Tensile strength: 111N (main cable tension)
• Salt spray test: 500h (K class, stainless steel passivation) 500h (W class, aluminum alloy cadmium plating) 48h (F class, aluminum alloy nickel plating)
