S3107A Single-channel Optical Receiving Module

S3107A is a miniature SDI video optical receiver module. The component supports 3G-SDI and SMPTE424M protocols, the transmission rate is 270Mbps to 2.97Gbps, the working temperature is -55°C to 85°C, the optical interface adopts a customized 8# optical pin interface, the electrical interface is 8-pin soldering pins, and the module package size is Ø8mmх24.7mm.
Technical documentation Datasheet S3107A Single-channel Optical Receiving Module

S3107A (1310nm) Single-channel Optical Receiving Module

Product Description
S3107A is a miniature SDI video optical receiver module. The component supports 3G-SDI and SMPTE424M protocols, the transmission rate is 270Mbps to 2.97Gbps, the working temperature is -55°C to 85°C, the optical interface adopts a customized 8# optical pin interface, the electrical interface is 8-pin soldering pins, and the module package size is Ø8mmх24.7mm.

Product Features
• 8# optical pin interface, 62.5/125um optical interface
• Supports SMPTE424M protocol
• 270Mbps ~ 2.97Gbps transmission rate
• Dimensions: Ø8mmх24.7mm
• Embedded in the connector, installed on the 8# four-coaxial contact piece node
• Signal GND and shell common ground
